Industrial Multi-Purpose Bamboo Dehydrator & Coconut Dryer Machine – High Efficiency Food Drying Equipment with Custom Temperature Control
The MeiYa Industrial Multi-Purpose Dehydrator is engineered to meet the rigorous demands of large-scale food processing, specializing in bamboo shoots, coconut products, and diverse agricultural goods. Combining high-efficiency heat pump technology, customizable temperature controls, and stainless steel durability, this machine ensures optimal drying results while adhering to global food safety and sustainability standards.
Core Innovations & Technology
1. Dedicated Drying for Bamboo & Coconut
• Bamboo Shoot Processing: Maintain precise temperatures (40–55°C) to remove moisture while preserving natural texture and nutrients like dietary fiber and antioxidants.
• Coconut Products: Adjust settings for shredded coconut, coconut milk powder, or copra, with humidity control to prevent oil rancidity.
• Multi-Purpose Flexibility: Efficiently dry fruits (e.g., mangoes, bananas), herbs, and spices in the same system.
2. Custom Temperature & Humidity Control
• Wide Temperature Range (30–80°C): Optimize drying conditions for sensitive materials like bamboo (lower temps) or dense coconut flesh (higher temps).
• Smart Touchscreen Interface: Pre-programmed settings for 20+ food types and real-time adjustments via a 10-inch digital panel.
3. Energy-Efficient Heat Pump Design
• 70% Energy Savings: Closed-loop heat recovery technology reduces power consumption compared to conventional dryers.
• Solar Compatibility: Integrate renewable energy systems to align with carbon-neutral goals.
4. Industrial-Grade Durability
• 304 Stainless Steel Trays & Chamber: Corrosion-resistant, easy to clean, and compliant with FDA 21 CFR Part 117 hygiene standards.
• Modular Tray System: Expand capacity from 500 kg/day to 5 tons/day for scalability.
Applications & Workflow
Bamboo Shoot Drying Protocol
- Preparation: Slice bamboo shoots uniformly for consistent airflow.
- Low-Temp Drying: Set to 45°C with 25% RH to retain crispness and nutrients.
- Final Cure: Reduce moisture to <12% for long-term storage or export.
Coconut Processing
• Shredded Coconut: Dry at 60°C to achieve <5% moisture for snacks or baking ingredients.
• Copra Production: High-temperature cycles (70–75°C) ensure efficient oil extraction readiness.
Market Advantages
✅ Nutrient Retention & Quality
• 95% Nutrient Preservation: Lab-tested retention of vitamins in fruits and antioxidants in bamboo shoots.
• Aroma & Texture Consistency: Uniform airflow eliminates hotspots, critical for premium coconut and bamboo products.
✅ Cost-Effective Operations
• ROI in 12–18 Months: Energy savings and reduced waste boost profitability for large-scale producers.
• Low Maintenance: Self-cleaning condensers and removable trays minimize downtime.
✅ Global Compliance
• CE, ISO 9001, and HACCP Certified: Meets EU, USDA, and ASEAN export requirements.
Technical Specifications
• Material: 304 stainless steel (trays, chamber, and housing)
• Temperature Range: 30–80°C
• Capacity: 500 kg–5 tons/day (modular)
• Power: 5.5–40 kW (customizable)
• Certifications: CE, ISO 9001, FDA
Why Choose MeiYa?
• Proven in Agri-Processing: Trusted by bamboo farms in Southeast Asia and coconut processors in the Caribbean.
• 24/7 Support: On-site installation, training, and lifetime technical assistance.
Transform Raw Materials into High-Value Exports
From nutrient-rich bamboo shoots to shelf-stable coconut products, MeiYa’s industrial dehydrator delivers precision, efficiency, and compliance.
📧 Contact us today for a free drying trial or customized quote!
MeiYa Heat Pump Dryer Machine
- No MOQ & Customization Unlimited
- Drying + Dehumidify + Cooling
- PLC + Touch Screen Control
- 7-10 Days Delivery Time
Parameter:
| Single dryer+drying chamber | ||||
| Model | Unit | MY-03RD | MY-06RD | MY-12RD |
| Power input | KW | 5.5 | 9.5 | 19.4 |
| power supply | V/PH/HZ | 380V/3PH,50/60HZ | 380V/3PH,50/60HZ | |
| 220V/1PH,50/60HZ | ||||
| Rated current | A | 9.6A(380V),22A(220V) | 17.0 | 30.0 |
| Heating capacity | KW | 10.5 | 21.0 | 42.0 |
| Cooling capacity | KW | 7.8 | 18.0 | 32.0 |
| Dehumidity | L/H | 12.0 | 25.0 | 50.0 |
| Max temperature | ℃ | ≤75 | ≤75 | ≤75 |
| Working condition | ℃ | 0-43 | 0-43 | 0-43 |
| Electric shock protection grade | 1 | 1 | 1 | |
| Max exhause pressure | M(P)a | 30 | 30 | 30 |
| Noise | d(B(A | 75 | 75 | 75 |
| Power consumption/H | KWH | 4.8 | 8.5 | 15.0 |
| Electric heater | KW | 3.0 | 6.0 | 12.0 |
| Blowing type | / | HORIZONTAL BLOWING TYPE | ||
| Demsnssion of dryer | MM | 3160*2070*2200 | 5700*2170*2200 | 5810*3230*2200 |
| Weight | KG | 180 | 285 | 480 |
Buying Guiding:
Recommend drying machine+Drying chamber sizes
| ITEM | DESCRIPTION | PRODUCT CAPACITY | DRYING CHAMBER SIZE |
| 1 | One unit MY-03RD+Drying chamer | 300/batch | 4000*2000*2200 |
| 2 | One unit MY-06RD+Drying chamer | 600/batch | 6000*2800*2200 |
| 3 | One unit MY-12RD+Drying chamer | 1300/batch | 6000*3000*2200 |
| 4 | Two unit MY-03RD+Drying chamer | 1200/batch | 7000*2200*2200 |
| 5 | Two unit MY-06RD+Drying chamer | 1500/batch | 10000*2800*2200 |
| 6 | Two unit MY-12RD+Drying chamer | 3500/batch | 10000*3000*2200 |
Our Projects:
Our Factory:
Production Processing:
Drying Machine Components:
Standard Working Modes:
- Typically 3 modes available:
- Drying Only
- Rapid temperature rise; unable to discharge moist air
- Drying + Dehumidify
- Chamber temperature rises while discharging moist air
- Cooling
- Temperature can drop to 10°C (minimum)
- Important Note:
- If temperature control becomes unstable, switch to Temperature & Humidity Mode.
- Drying Only
Drying Machine Common Issues
- Q1: High Pressure Protection
- A1.1: Hot air circulation system failure
- AC contactor overload protection
- (Check phase loss/loose terminals/voltage instability)
- Partial fan failures
- (Verify switches configuration and burnt components)
- Mechanical fan damage
- (Replacement or removal required)
- AC contactor overload protection
- A1.2: Tray overloading phenomenon
- Optimal spacing: 8-10cm between trays
- (Causes airflow obstruction in drying chamber)
- Optimal spacing: 8-10cm between trays
- A1.3: Electronic expansion valve anomalies ▪ Automatic minimum aperture adjustment
- (Sensor calibration: Reposition or exchange Sensor 1/2) ▪ Valve body malfunction
- (Manual rotation intervention needed)
- (Sensor calibration: Reposition or exchange Sensor 1/2) ▪ Valve body malfunction
- A1.4: Chamber overheating condition
- (Temperature parameter adjustment solution)
- A1.5: Refrigerant specification error
- (High-temperature type gas recharge required)
- A1.1: Hot air circulation system failure
- Q2: Low Pressure Protection
- A2.1: Gas leakage scenario
- (Leak detection and repair protocol)
- A2.2: Extreme cold environment
- (Extended check intervals or R22/R417A refill)
- A2.3: Valve aperture deficiency
- (Expansion valve opening adjustment method)
- A2.1: Gas leakage scenario
- Q3: Exhaust Temperature Overload
- A3.1: Gas leakage recurrence
- (Refers to Q2.1 resolution process)
- A3.2: Valve operational failure
- (See A1.3.2 corrective action)
- A3.1: Gas leakage recurrence
- Q4: Sensor Malfunction
- A4.1: Temperature sensor defect
- (Replacement procedure guidelines)
- A4.1: Temperature sensor defect
- Q5: Moisture Evacuation Failure
- A5.1: Dehumidification fan damage
- A5.2: Control system malfunction
- A5.3: Power delivery irregularity
Our Services
A. Payment Service
- T/T (Telegraphic Transfer)
• Applicable to all transaction types. - L/C (Letter of Credit)
• Exclusively available for container orders. - Western Union
• Recommended for sample orders and spare parts procurement.
B. Technical Service
- Capacity Analysis & Model Recommendation
• We provide customized capacity calculations and optimal model selections based on operational requirements. - Professional Technical Support
• Comprehensive refrigeration and electronic engineering assistance for installation, debugging, and system operation. - Spare Parts & Post-Warranty Support
• Genuine spare parts and technical guidance provided during and after the warranty period. - Training Programs
• On-site or factory-based training courses available upon request.
C. After-Sales Service
- Technical Assistance
• Continuous support for installation, operation, and maintenance. - Warranty Policy
• 12-month warranty coverage with optional extension. - Cost-Effective Post-Warranty Support
• Spare parts and technical services offered at competitive rates after warranty expiration.
