Commercial-Grade Heat Pump Food Dehydrator for Fruits, Vegetables & Meat – Energy-Saving Industrial Dryer
The MeiYa Commercial Heat Pump Dehydrator is a state-of-the-art solution designed for high-efficiency drying of fruits, vegetables, meat, and other perishable goods. By integrating adaptive heat pump technology and AI-driven process optimization, this industrial-grade machine prioritizes energy savings, nutrient retention, and streamlined workflows, aligning with global sustainability goals.
Core Innovations & Workflow Excellence
- Adaptive Drying Process with Preset Profiles
• 28+ Preset Programs: Preconfigured settings for fruits (e.g., mangoes, berries), vegetables (leafy greens, root crops), and meats (jerky, poultry) optimize temperature and humidity based on material type.
• Real-Time Adjustments: Sensors monitor exhaust air temperature and humidity, dynamically adjusting blower speed (20–50Hz) and heating output to maintain precision. - Energy-Saving Heat Pump Technology
• Closed-Loop Heat Recovery: Recycles 90% of waste heat, reducing energy consumption by 30–80% compared to traditional dryers.
• Low-Temperature Precision: ◦ Fruits: Gentle cycles at 35–55°C preserve 95% of vitamins (e.g., vitamin C in citrus) and natural sugars.
◦ Vegetables: Retain chlorophyll and antioxidants (e.g., spinach, carrots) at 40–60°C with uniform airflow.
◦ Meat Jerky: High-efficiency drying at 55–75°C achieves <8% moisture while ensuring food safety compliance. - Smart Automation & Workflow Integration
• AI-Driven Predictive Maintenance: Alerts for filter replacements and system optimizations reduce downtime by 30%, ensuring continuous production.
• Intermittent Operation Mode: Automatically switches to low-power standby during idle periods, cutting energy waste.
Certifications & Market Compliance
• Global Standards: CE-certified with Halal, Kosher, USDA Organic, and BRCGS endorsements, ensuring compliance for EU, North American, and Asian markets.
• Sustainability Alignment: Meets EU Green Deal 2030 criteria through renewable energy compatibility (solar/wind-ready design).
Success Stories & Cost Efficiency
- Tropical Fruit Processing in Thailand
A cooperative reduced energy costs by 65% while drying mangoes at 50°C, preserving 97% of vitamin C for global snack brands. - Vegetable Valorization in Spain
A facility achieved ISO22000 certification by dehydrating spinach and peppers with 70% energy savings, cutting operational costs by $35,000 annually. - Grass-Fed Jerky Production in Australia
A plant secured USDA Organic certification through precision drying, expanding exports to North America with a 12-month ROI.
Technical Specifications
• Temperature Range: 30–85°C
• Capacity: 200 kg–15 tons/day (modular)
• Energy Efficiency: 70% reduction vs. conventional dryers
• Certifications: CE, ISO22000, BRCGS, Halal
• Warranty: 12-month coverage with lifetime technical support
Why MeiYa?
• Proven Energy Savings: Validated by TÜV SÜD for heat pump performance and cost efficiency.
• Global Scalability: 24/7 technical support and training in 50+ countries.
Transform Raw Produce into Profitable, Nutrient-Rich Products
From vitamin-packed fruits to protein-rich jerky, MeiYa’s dehydrator delivers unmatched efficiency and market readiness.
Contact MeiYa today for a free drying trial or customized quote!
MeiYa Heat Pump Dryer Machine
- No MOQ & Customization Unlimited
- Drying + Dehumidify + Cooling
- PLC + Touch Screen Control
- 7-10 Days Delivery Time
Parameter:
| Single dryer+drying chamber | ||||
| Model | Unit | MY-03RD | MY-06RD | MY-12RD |
| Power input | KW | 5.5 | 9.5 | 19.4 |
| power supply | V/PH/HZ | 380V/3PH,50/60HZ | 380V/3PH,50/60HZ | |
| 220V/1PH,50/60HZ | ||||
| Rated current | A | 9.6A(380V),22A(220V) | 17.0 | 30.0 |
| Heating capacity | KW | 10.5 | 21.0 | 42.0 |
| Cooling capacity | KW | 7.8 | 18.0 | 32.0 |
| Dehumidity | L/H | 12.0 | 25.0 | 50.0 |
| Max temperature | ℃ | ≤75 | ≤75 | ≤75 |
| Working condition | ℃ | 0-43 | 0-43 | 0-43 |
| Electric shock protection grade | 1 | 1 | 1 | |
| Max exhause pressure | M(P)a | 30 | 30 | 30 |
| Noise | d(B(A | 75 | 75 | 75 |
| Power consumption/H | KWH | 4.8 | 8.5 | 15.0 |
| Electric heater | KW | 3.0 | 6.0 | 12.0 |
| Blowing type | / | HORIZONTAL BLOWING TYPE | ||
| Demsnssion of dryer | MM | 3160*2070*2200 | 5700*2170*2200 | 5810*3230*2200 |
| Weight | KG | 180 | 285 | 480 |
Buying Guiding:
Recommend drying machine+Drying chamber sizes
| ITEM | DESCRIPTION | PRODUCT CAPACITY | DRYING CHAMBER SIZE |
| 1 | One unit MY-03RD+Drying chamer | 300/batch | 4000*2000*2200 |
| 2 | One unit MY-06RD+Drying chamer | 600/batch | 6000*2800*2200 |
| 3 | One unit MY-12RD+Drying chamer | 1300/batch | 6000*3000*2200 |
| 4 | Two unit MY-03RD+Drying chamer | 1200/batch | 7000*2200*2200 |
| 5 | Two unit MY-06RD+Drying chamer | 1500/batch | 10000*2800*2200 |
| 6 | Two unit MY-12RD+Drying chamer | 3500/batch | 10000*3000*2200 |
Our Projects:
Our Factory:
Production Processing:
Drying Machine Components:
Standard Working Modes:
- Typically 3 modes available:
- Drying Only
- Rapid temperature rise; unable to discharge moist air
- Drying + Dehumidify
- Chamber temperature rises while discharging moist air
- Cooling
- Temperature can drop to 10°C (minimum)
- Important Note:
- If temperature control becomes unstable, switch to Temperature & Humidity Mode.
- Drying Only
Drying Machine Common Issues
- Q1: High Pressure Protection
- A1.1: Hot air circulation system failure
- AC contactor overload protection
- (Check phase loss/loose terminals/voltage instability)
- Partial fan failures
- (Verify switches configuration and burnt components)
- Mechanical fan damage
- (Replacement or removal required)
- AC contactor overload protection
- A1.2: Tray overloading phenomenon
- Optimal spacing: 8-10cm between trays
- (Causes airflow obstruction in drying chamber)
- Optimal spacing: 8-10cm between trays
- A1.3: Electronic expansion valve anomalies ▪ Automatic minimum aperture adjustment
- (Sensor calibration: Reposition or exchange Sensor 1/2) ▪ Valve body malfunction
- (Manual rotation intervention needed)
- (Sensor calibration: Reposition or exchange Sensor 1/2) ▪ Valve body malfunction
- A1.4: Chamber overheating condition
- (Temperature parameter adjustment solution)
- A1.5: Refrigerant specification error
- (High-temperature type gas recharge required)
- A1.1: Hot air circulation system failure
- Q2: Low Pressure Protection
- A2.1: Gas leakage scenario
- (Leak detection and repair protocol)
- A2.2: Extreme cold environment
- (Extended check intervals or R22/R417A refill)
- A2.3: Valve aperture deficiency
- (Expansion valve opening adjustment method)
- A2.1: Gas leakage scenario
- Q3: Exhaust Temperature Overload
- A3.1: Gas leakage recurrence
- (Refers to Q2.1 resolution process)
- A3.2: Valve operational failure
- (See A1.3.2 corrective action)
- A3.1: Gas leakage recurrence
- Q4: Sensor Malfunction
- A4.1: Temperature sensor defect
- (Replacement procedure guidelines)
- A4.1: Temperature sensor defect
- Q5: Moisture Evacuation Failure
- A5.1: Dehumidification fan damage
- A5.2: Control system malfunction
- A5.3: Power delivery irregularity
Our Services
A. Payment Service
- T/T (Telegraphic Transfer)
• Applicable to all transaction types. - L/C (Letter of Credit)
• Exclusively available for container orders. - Western Union
• Recommended for sample orders and spare parts procurement.
B. Technical Service
- Capacity Analysis & Model Recommendation
• We provide customized capacity calculations and optimal model selections based on operational requirements. - Professional Technical Support
• Comprehensive refrigeration and electronic engineering assistance for installation, debugging, and system operation. - Spare Parts & Post-Warranty Support
• Genuine spare parts and technical guidance provided during and after the warranty period. - Training Programs
• On-site or factory-based training courses available upon request.
C. After-Sales Service
- Technical Assistance
• Continuous support for installation, operation, and maintenance. - Warranty Policy
• 12-month warranty coverage with optional extension. - Cost-Effective Post-Warranty Support
• Spare parts and technical services offered at competitive rates after warranty expiration.
